1/2 Carbide Square End Mill 4 Flute AlTiN Coating Pack of 2 V199
Sale price
$18.90
Regular price $69.83
Skip to product information
Package Included: 1pc 1/2 ' carbide square end Mill.
Material: Made of micro grain carbide. Carbide has higher hardness and wear resistance and excellent cutting performance than high-speed steel.
Coating: AlTiN, high aluminum content provides excellent hot hardness and oxidation resistance.
HRC 45 deg :carbide end mill tools excel at working carbon steels (~ HB225), alloy steels (HB225 ~ 325), pre-hardened steels (up to HRC45), hardened Steels (HRC40 ~ 45), cast iron.
Flutes:4 Flutes,high rigidity ,widely used in shallow slot,profile milling,and finish machining.
1/2 Carbide Square End Mill 4 Flute AlTiN Coating Pack of 2 V199
Sale price
$18.90
Regular price $69.83
Shipping calculated at checkout.
Package Included: 1pc 1/2 ' carbide square end Mill.
Material: Made of micro grain carbide. Carbide has higher hardness and wear resistance and excellent cutting performance than high-speed steel.
Coating: AlTiN, high aluminum content provides excellent hot hardness and oxidation resistance.
HRC 45 deg :carbide end mill tools excel at working carbon steels (~ HB225), alloy steels (HB225 ~ 325), pre-hardened steels (up to HRC45), hardened Steels (HRC40 ~ 45), cast iron.
Flutes:4 Flutes,high rigidity ,widely used in shallow slot,profile milling,and finish machining.
Specifications:
4 flutes
Cutting Diameter: 0.5 inch
Cutting Length: 1.377 inch
Shank Diameter: 0.5 inch
Full Length: 2.952 inch
Raw Material:Use Zigong YG10X,high hardness,good wear resistance and corrosion resistance.
Cutting Parameter
Cutting depth =220（120-180）m/min
Cut deep =1/3D(1/8-1/2D)
Cut width =1/2D(1/4-1D)
Single edge feed = 0.15mm（0.02-0.2）
Please adjust the parameters accroding to the material and hardness of workpieces. Helix Angle:35 deg,high adaptability to the material and hardness of work pieces,widely wsed to mold and product processing and cost efficient.
